Hashatron | Craft Series Double Wall Washer

Hashatron | Double Wall Washing for Your Craft

Craft Series Double Wall Washer

Want to automate your craft washing operation without sacrificing quality? Hashatron’s Craft Series Double Wall Washers are a powerful easy to use single operator washer capable of quick cycle time and reduced labor over conventional manual washing. All craft series washer utilize our patent pending removeable stainless steel wash basket eliminating the need for fragile nylon wash bags. Our stainless steel wash basket also allows for unmatched water removal of spent product once the wash cycle is complete by allowing the operator to spin out water from waste product prior to disposal. Since one size does not fit all and bigger sometimes isn’t always better our line of craft series washers are fabricated in sizes from 20 to 200 gallons. All washers kits come complete with the following equipment.

DOWNLOAD SPEC SHEET

Craft Series Single Walled Washer

Standard Features

  • Double wall washing vessel with manual opening and locking lid with full view poly carbonate sight window
  • Wash down grade motor with gear reduction
  • Stainless steel removable washing basket with internal paddle mounts
  • 4 standard removable paddles
  • Hashatron color touch screen control cabinet with wash recipe creation, recirculation pump and high speed dry cycle de watering settings
  • Single wall collection vessel with false floor & drain valve kit
  • 1.5″ electric closed loop pump and hose kit
  • Neoprene insulation jackets on washer & collection vessel
  • 1 year parts & labor warranty

Recommended Fresh Frozen Capacities Per Hour

  • 20 Gallon – 4,000 grams
  • 50 Gallon – 11,000 grams
  • 80 Gallon – 15,000 grams
  • 100 Gallon – 20,000 grams
  • 150 Gallon – 28,000 grams
  • 200 Gallon – 38,000 grams

Optional Equipment

  • Powered basket removal lift arm
  • Nylon full mesh bubble bag collection kit
  • Pre-Chill vessel system with pressurized cold water spray kit
  • Vibratory collection vessel with stainless steel collection sieves
  • Wash basket clean out station
  • Spare wash basket
  • CIP System

Downloadable Resources

Agitator Comparison | Pre-Chill Tanks | Sieve Comparison
